    FR4 OEM Copy Pcb Board Reverse Engineering Electronic Board Assembly

    FR4 OEM Electronics Copy PCBA Boards PCB Reverse Engineering

    Shenzhen Yideyi Technology Co., Ltd is a professional PCB manufacturer, which is located in Shenzhen, China. After many years development, it has become a company which integrates research & development, reverse engineering,manufacture, SMT and sales.


    The key markets we serve include medical and healthcare, industrial control and automotive electronics. Occupying 9000 sq m, with more than 600 employee, 12 SMT lines etc., our facility meets or exceeds the highest regulatory, quality and traceability requirements.


    We are the provider of take a circuit board and fully reverse engineer it to provide complete manufacturing CAD data and even native format schematics. Our system includes the ability to capture precise form, fit and function for all layers of the PCB, including all inner layer geometries, drill, drill plating and layer thickness, cutouts, outline, silkscreen, and even blind or buried vias.


    Data generated from PCB Reverse Engineering can be used either to manufacture replacement parts, or provide insight in repairing existing parts when schematics may not be available.


    Unique Niche

    Our systems are a critical component to the hardware support strategy for numerous military, governmental, aerospace, nuclear, utility, automotive and commercial firms. They rely on our system to keep their mission-critical hardware operational each and every day.


    Unique Technology

    Internally developed software coupled with our low-cost vision platform and NIST certified calibration equipment ensures that our system is a solution that is custom tailored for your application. Our hardware and software have been specifically designed to maintain an excellent price-performance ratio, maximize your ROI and provide a unique set of tools for effective and efficient reverse engineering, regardless of the scale of your project.


    Unique Process

    Over our 10 years in business, we have continuously improved our process to support cutting edge technology. Whether a circuit card has two or twelve layers, blind or buried vias, and the substrate is FR4 or Thermount, we have the process knowledge to ensure your success.


    PCB Reverse Engineering Services

    Expertise in Schematic Generation and reproduction of existing Printed Circuit Boards

    PCB Reverse Engineering Services General Information

    Reasons to reverse engineer an existing circuit board design may include:


    Lost or corrupt files with the need to modify the current design.

    PCB is no longer manufactured and replacements are required.


    Our Reverse Engineering Services can take an existing PCB or Gerber data and create a complete documentation package required for manufacturing. This documentation package includes:

    Fabrication drawings

    Bill of materials (BOM)

    Schematic capture files

    Gerber files

    CAD design

    Drill data

    Additionally, we can provide free samples for your testing

    Additional AOI Capabilities:

    Check Gerber image vs. PCB image

    Compare Gerber image vs. Gerber image

    Compare PCB image to another PCB image


    How PCB Reverse Engineering Would Help PCB Design & Development?


    PCB reverse engineering is a reverse research technology that uses a series of reverse research techniques to obtain a PCB design, circuit schematic and a BOM for an existing & matual electronic design. A new product development that used to take two or three years to develop, now through reverse engineering technolgy, may take only a few months to complete.


    In the past decade, the development of electronic technology has been changing with each passing day, and many electronic products have been upgraded at least once a year. Future electronic product updates may be faster. Many electronics engineers have felt that simply using conventional R&D methods can no longer meet the fast steps of modern electronic product replacement, and since there have been millions of matual design in the market, reverse engineering becomes an approach to fast adopt the market pace and catch up the top runners.


    YDY service:


    1. PCBA, PCB assembly: SMT & PTH & BGA

    2. PCBA and enclosure design

    3. Components sourcing and purchasing

    4. Quick prototyping

    5. Plastic injection molding

    6. Metal sheet stamping

    7. Final assembly

    8. Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)

    9. Custom clearance for material importing and product exporting

    10. PCBA reverse engineering

    11. Professtional R&D team

    12. PCB Layout Design


    Reverse Engineering For Quote:

    sample for analysis


    Files Requested For Quote:

    In order to provide you with the most efficient and accurate quote on manufacturing the requested unit, we ask that you provide us with the following information:


    1. Gerber file,PCB file,Eagle file or CAD file are all acceptable

    2. A detailed bill of materials (BOM)

    3. Clear pictures of PCB or PCBA sample for us

    4. Quantity and delivery required

    5. Test method for PCBA to guarantee 100% good quality products.

    6. Schematics file for PCB design if need to do function test.

    7. A sample if available for better sourcing

    8. CAD files for enclosure manufacturing if required

    9. A complete wiring and assembly drawing showing any special assembly instructions if required


    PCB Assembly Manufacturing Procedures:


    Program Management


    PCB Files → DCC → Program Organizing → Optimization → Checking


    SMT Management

    PCB Loader → Screen Printer → Checking → SMD Placement → Checking → Air Reflow → Vision Inspection → AOI → Keeping


    PCBA Management

    THT→Soldering Wave (Manual Welding) → Vision Inspection → ICT → Flash → FCT → Checking → Package → Shipment


    Each board is carefully examined by our dedicated inspection team using AOI and high magnification viewers.

    Using our X-Ray machine, we test PCBs to component level and all wiring is fully inspected and tested. Flash

    testing and earth bonding tests can also be undertaken where required



    PCB Manufacture Capacity


    Assembly detailsPCBA SMT and Thru-hole, ISO SMT and DIP lines
    Testing on productsTesting jig/mold , X-ray Inspection, AOI Test, Functional test
    QuantityMin quantity : 1pcs. Prototype, small order, mass order, all OK
    Files neededPCB : Gerber files(CAM, PCB, PCBDOC)
    Components : Bill of Materials(BOM list)
    Assembly : Pick-N-Place file
    PCB Panel SizeMin size : 0.25*0.25 inches(6*6mm)
    Max size : 1200*600mm
    Components detailsPassive Down to 0201 size
    BGA and VFBGA
    Leadless Chip Carriers/CSP
    Double-sided SMT Assembly
    Fine BGA Pitch to 0.2mm(8mil)
    BGA Repair and Reball
    Part Removal and Replacement
    Component packageCut Tape, Tube, Reels, Loose Parts
    PCB+ assembly process(PCBA)Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity

    FR4 OEM Copy Pcb Board Reverse Engineering Electronic Board Assembly


    High quality and on-time delivery is always our promise:


    FR4 OEM Copy Pcb Board Reverse Engineering Electronic Board Assembly


    FR4 OEM Copy Pcb Board Reverse Engineering Electronic Board Assembly


    FAQ:


    Q1. How to keep our product information and design file secret ?
    We are willing to sign a NDA effect by customers side local law and promising to keep customers data in high confidential level.


    Q2. How long does it take for PCB and PCBA Quote ?
    PCBs quotation within 2 hours can finished the PCBA depend on the components
    quantity,if simple, within 6 hours can finished,once complex and more,the 12- 36 hours
    can be finished.


    Q3. Please note that the following detail will speed up evaluation:
    Material:
    Board thickness:
    Copper thickness:Surface finish:
    Solder mask color:
    Silkscreen color:


    Q4. How to make sure the PCBAs are completely well recieved?
    We will pack with aluminum bag, and insert card, up and bottom card with stable cartons.

    Q5. How to ship the PCBAs?
    For small packages, we will ship the boards to you by DHL,UPS,FEDEX,TNT. Door to door service! For mass production, we could ship by air, by sea.


    Q6. How to make sure the function is fine?
    We could make sample/prototype and do functional testing before mass production.
