Shenzhen Yideyi Technology Co., Ltd is a professional PCB
manufacturer, which is located in Shenzhen, China. After many years
development, it has become a company which integrates research &
development, manufacture, SMT and sales.
Our products are widely used in meter, medical, solar energy,
mobile, communication, industrial control, power
electronics,security, consuming, computer, automotive, aerospace,
military and so on. Over 75% of our products are exported to
Europe, North America, Japan and other Asia Pacific countries.
Based on many years of development, we have high-qualified
management team, experienced R&D team and skilled employees,and
possess advantaged supply chain, commitment to quality,and
dedication to our customers service. Encouraging innovation and
keeping improving. Besides achieving corporate and customer values,
we also create a favorable atmosphere for employees to achieve
personal values.
The definition of multilayer PCB is a PCB that is made with three
or more conductive copper foil layers. These appear as several
layers of double-sided circuit boards, laminated and glued together
with layers of heat-protective insulation between them.
DIP capability:
• A-8 of semi-assembly work line with 3 set wave soldering machines
• B-4 of high/low-temperature burn-in test ovens for the burn-in
tested required products
• All products are 100% inspected and tested during the DIP process
Our SMT Advantages:
• Strict product liability, taking IPC-A-160 standard
• Engineering pretreatment before production
• Production process control (5Ms)
• 100% E-test, 100% visual inspection, including IQC, IPQC, FQC,
OQC
• 100% AOI inspection, including X-ray, 3D microscope and ICT
• High-voltage test, impedance control test
• Micro section, soldering capacity, thermal stress test, shocking
test
• In-house PCB production
• No minimum order quantity and free sample
• Focus on low to medium volume production
• Quick and on-time delivery
SMT Production processes:
Material Receiving → IQC → Stock → Material to SMT → SMT Line
Loading → Solder Paste/Glue Printing → Chip Mount → Reflow → 100%
Visual Inspection → Automated Optical Inspection (AOI) → SMT QC
Sampling → SMT Stock → Material to PTH → PTH Line Loading → Plated
Through Hole → Wave Soldering → Touch Up → 100% Visual Inspection →
PTH QC Sampling → In-Circuit Test (ICT) → Final Assembly →
Functional Test (FCT) → Packing → OQC Sampling → Shipping
PCB Assembly Manufacturing Procedures:
Program Management
PCB Files → DCC → Program Organizing → Optimization → Checking
SMT Management
PCB Loader → Screen Printer → Checking → SMD Placement → Checking →
Air Reflow → Vision Inspection → AOI → Keeping
PCBA Management
THT→Soldering Wave (Manual Welding) → Vision Inspection → ICT →
Flash → FCT → Checking → Package → Shipment
Our service
1. SMT service;
2. Design service, Gerber drawings;
3. Good quality and fast delivery with lower price than double side
PCB.
4. Specifications of LEAD Free HASL 1 Layer / Single Side Rigid
PCB/PCBA:
1) Base material: FR-1(94v0), FR-4, CEM-1,
2) Max Board size: 600*600mm
3) Board thickness: 0.2mm/0.6mm/0.8mm/1.2mm/1.6mm/3.2mm
4) Copper thickness: 0.5oz , 1oz , 2oz ,3oz,4oz, 5oz ,7oz , 11oz
5) Special tech: BGA, PTH, Blind and buried vias
6) Profile: V-scoring, V-cutting, punching, etching, milling,
routing
7) Surface treatment: HASL, OS, Immersion gold, gold plated
(coating)
8) With best price to USA, South American, India, South Africa and
Europe
9) Main market: USA, EGYPT, Europe, South American, mid-east
10) Compliant: UL, ROHS, ISO9001-2000
11) Standard: IPC-A-600F, IPC-D-300G, MIL-STD-105D LEVEL II
12) Application: Home appliances, electronics, digital camera, LCD
TV sets, medical equipments, telecommunication, LED lightings,
street light, mobile phone, computer, laptop test equipment and
power meter, electrical weighing scale, night
13) Small quantity and prototypes acceptable
14) Lead time: 5-7days for prototypes, 9-13days for mass production
15) Available Service: OEM, 24hrs service for fast prototype
Files Requested For Quote:
In order to provide you with the most efficient and accurate quote
on manufacturing the requested unit, we ask that you provide us
with the following information:
1. Gerber file,PCB file,Eagle file or CAD file are all acceptable
2. A detailed bill of materials (BOM)
3. Clear pictures of PCB or PCBA sample for us
4. Quantity and delivery required
5. Test method for PCBA to guarantee 100% good quality products.
6. Schematics file for PCB design if need to do function test.
7. A sample if available for better sourcing
8. CAD files for enclosure manufacturing if required
9. A complete wiring and assembly drawing showing any special
assembly instructions if required
