    0.4 Mm 8 Layer Multilayer Printed Circuit Board Mainboard Surface Laminar Circuit

    Ask Lasest Price
    Brand Name : YDY
    Model Number : M-002
    Certification : ISO13485, IATF16949, ISO9001,IOS14001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 50000pcs/month
    Delivery Time : 1-10 working days
    • Product Details
    • Company Profile

    0.4 Mm 8 Layer Multilayer Printed Circuit Board Mainboard Surface Laminar Circuit

    Multilayer Printed Circuit Board Main Board Surface Laminar Circuit ​


    Shenzhen Yideyi Technology Co., Ltd is located in the beautiful scenery of Shenzhen city of Guangdong Province, it has modernized standard workshop of 9000 square meters, more than 500 employees, is a professional manufacturers of production of aluminum plate, single, double, multilayer printed circuit board and flexible circuit board.


    We have a strong engineering team, high quality and efficient production and fast and global service in the industry are in a leading position, based on quality, service, efficiency and win-win, our processing products are widely used in computer, communication, auto parts products, medical equipment, precision instruments, aviation equipment, and other fields, we also provide the OEM service to customers in Europe and America, South Korea, Japan, Southeast Asia, the Middle East and Latin America. Companies adhering to thought of the “management of science and technology and creative enterprise”, continue develop new process and new products so that ahead of competition in the market. The perfect quality management system can provide a solid guarantee for us to produce high quality products. Our company can provide copy board, sample, mass production service, and provide the express production services for the customers and so on.


    To produce a multi-layer PCB, alternating layers of epoxy-infused fiberglass sheet called prepreg and conductive core materials are laminated together under high temperature and pressure using a hydraulic press. The pressure and heat causes the prepreg to melt and join the layers together.


    Our Advantages:


    • Strict product liability, taking IPC-A-160 standard

    • Engineering pretreatment before production

    • Production process control (5Ms)

    • 100% E-test, 100% visual inspection, including IQC, IPQC, FQC, OQC

    • 100% AOI inspection, including X-ray, 3D microscope and ICT

    • High-voltage test, impedance control test

    • Micro section, soldering capacity, thermal stress test, shocking test

    • In-house PCB production

    • No minimum order quantity and free sample

    • Focus on low to medium volume production

    • Quick and on-time delivery


    SMT Production processes:


    Material Receiving → IQC → Stock → Material to SMT → SMT Line Loading → Solder Paste/Glue Printing → Chip Mount → Reflow → 100% Visual Inspection → Automated Optical Inspection (AOI) → SMT QC Sampling → SMT Stock → Material to PTH → PTH Line Loading → Plated Through Hole → Wave Soldering → Touch Up → 100% Visual Inspection → PTH QC Sampling → In-Circuit Test (ICT) → Final Assembly → Functional Test (FCT) → Packing → OQC Sampling → Shipping


    PCB Assembly Manufacturing Procedures:

    Program Management


    PCB Files → DCC → Program Organizing → Optimization → Checking


    SMT Management

    PCB Loader → Screen Printer → Checking → SMD Placement → Checking → Air Reflow → Vision Inspection → AOI → Keeping


    PCBA Management

    THT→Soldering Wave (Manual Welding) → Vision Inspection → ICT → Flash → FCT → Checking → Package → Shipment


    Our service


    1. SMT service;

    2. Design service, Gerber drawings;

    3. Good quality and fast delivery with lower price than double side PCB.

    4. Specifications of LEAD Free HASL 1 Layer / Single Side Rigid PCB/PCBA:


    1) Base material: FR-1(94v0), FR-4, CEM-1,

    2) Max Board size: 600*600mm

    3) Board thickness: 0.2mm/0.6mm/0.8mm/1.2mm/1.6mm/3.2mm

    4) Copper thickness: 0.5oz , 1oz , 2oz ,3oz,4oz, 5oz ,7oz , 11oz

    5) Special tech: BGA, PTH, Blind and buried vias

    6) Profile: V-scoring, V-cutting, punching, etching, milling, routing

    7) Surface treatment: HASL, OS, Immersion gold, gold plated (coating)

    8) With best price to USA, South American, India, South Africa and Europe

    9) Main market: USA, EGYPT, Europe, South American, mid-east

    10) Compliant: UL, ROHS, ISO9001-2000

    11) Standard: IPC-A-600F, IPC-D-300G, MIL-STD-105D LEVEL II

    12) Application: Home appliances, electronics, digital camera, LCD TV sets, medical equipments, telecommunication, LED lightings, street light, mobile phone, computer, laptop test equipment and power meter, electrical weighing scale, night

    13) Small quantity and prototypes acceptable

    14) Lead time: 5-7days for prototypes, 9-13days for mass production

    15) Available Service: OEM, 24hrs service for fast prototype


    Files Requested For Quote:


    In order to provide you with the most efficient and accurate quote on manufacturing the requested unit, we ask that you provide us with the following information:


    1. Gerber file,PCB file,Eagle file or CAD file are all acceptable

    2. A detailed bill of materials (BOM)

    3. Clear pictures of PCB or PCBA sample for us

    4. Quantity and delivery required

    5. Test method for PCBA to guarantee 100% good quality products.

    6. Schematics file for PCB design if need to do function test.

    7. A sample if available for better sourcing

    8. CAD files for enclosure manufacturing if required

    9. A complete wiring and assembly drawing showing any special assembly instructions if required


    ProcessItemMass production capability
    SMTPrintingMax PCB size900*600mm²
    Max PCB weight8kg
    Solder paste printing tolerance±25μm(6σ)
    System repeat calibration tolerance±10μm(6σ)
    Scraper pressure detectionpressure closed-loop control system
    SPIDetect Min BGA PAD to PAD distance100μm
    x-axis and Y-axis tolerance0.5μm
    False Rate≤0.1%
    MountComponent size0.3*0.15 mm²--200*125 mm²
    Component max height25.4mm
    BGA/CSP Min PAD spacing, and Min PAD diameter0.30mm,0.15mm
    Populate tolerance±22μm(3σ),±0.05°(3σ)
    PCB board size50*50 mm²-850*560 mm²
    PCB thickness0.3mm--6mm
    Populate Max components type500
    AOIDetect Min components01005
    Detect false typeIncorrect conponents,missing components,opposite direction,,component shift,Tombstone,Mounting on side,unsoldering,insufficient solder,Lead raised,Solder ball
    Foot warping detection3D Detection function
    ReflowTemperature Accuracy±1ºC
    Welding protectionnitrogen protection;(remaining oxygen<3000ppm)
    Nitrogen ControlNitrogen closed-loop control system,±200ppm
    3D X-RayMagnificationGeometric Magnification;:2000 times;System Magnification:12000times
    Resolution1μm /nm
    Rotation Angle &Slanting PerspectiveAny ±45°+360°rotation
    DIPPreelaborationAutomatic forming technologyComponent Automatic forming
    DIPDIP technologyAutomatic Insertion machine
    Wave solderingWave soldering typeOrdinary wave soldering
    Inclination angle of transport guide rail4--7°
    Temperature accuracy±3ºC
    Soldering protectionnitrogen protection
    Non-welding pressure contact technologyMax PCB board size800*600mm²
    Press down height accuracy±0.02mm
    Pressure Range0-50KN
    Pressure AccuracyStandard value:±2%
    Hold time0-9.999S
    Conformal coating technologyMax PCB board size500*475*6mm
    Max PCB board weight5kg
    Min Nozzle size2mm
    Other characteristicConformal coating pressure Programmable control
    ICT testtest levelDevice level test,Test hardware connection status.
    Test point>4096
    Test contentContact test ,Open/short test,Resistance capacitance test test,diode, triode,mosfet test,No power on hybrid test,Boundary scan chain test,Power on mixed mode test.
    Assembly and testProduction typeTouchPadMass production
    TWSMass production
    Gaming controllerMass production
    Life WatchMass production
    FT testtest levelPCB board system level test.Test System function status.
    Temperature cycling testTemperature range-60ºC--125ºC
    Rise/lower temperature rate>10ºC/min
    Temperature tolerance≤2ºC
    Other Reliability testburn-in test,Drop test, vibration test , Abrasion test ,Key life test.

    0.4 Mm 8 Layer Multilayer Printed Circuit Board Mainboard Surface Laminar Circuit


    0.4 Mm 8 Layer Multilayer Printed Circuit Board Mainboard Surface Laminar Circuit



    Trade Terms:


    1. Payment: T/T in advance (Western Union , paypal is welcomed)


    2. Production lead time 100PCS: 5-7days, 500~1000PCS: 7-10days, above 1000PCS 15-20days.


    3. Sample can be delivered in 3days


    4. Shipping freight are quoted under your requests


    5. Shipping port: Shen zhen,Mainland China


    6. Discounts are offered based on order quantities


    7. MOQ: 1PCS


    Package &Shipping Methods:


    1. Vacuum package with silica gel, Carton box with packing belt.

    2. By DHL, UPS, FedEx, TNT

    3. By EMS

    4. By sea for mass quantity according to customer's requirement


    We are the smart choice for you and the trusted source at the center of your deal. Welcome the win-win situation together.


    0.4 Mm 8 Layer Multilayer Printed Circuit Board Mainboard Surface Laminar Circuit


    FAQ:


    Q1. How to keep our product information and design file secret ?
    We are willing to sign a NDA effect by customers side local law and promising to keep customers data in high confidential level.


    Q2. What file formats do you accept for production?

    Gerber file: CAM350 RS274X

    PCB file: Protel 99SE, P-CAD 2001 PCB

    BOM: Excel (PDF,word,txt)


    Q3. Please note that the following detail will speed up evaluation:
    Material:
    Board thickness:
    Copper thickness:Surface finish:
    Solder mask color:
    Silkscreen color:


    Q4. How to make sure the PCBAs are completely well recieved?
    We will pack with aluminum bag, and insert card, up and bottom card with stable cartons.

    Q5. How to ship the PCBAs?
    For small packages, we will ship the boards to you by DHL,UPS,FEDEX,TNT. Door to door service! For mass production, we could ship by air, by sea.


    Q6. How to make sure the function is fine?
    We could make sample/prototype and do functional testing before mass production.
